Distanziali ruota da 20 mm compatibili con Ford Focus MK2, MK3. NERI. T4
Distanziali ruota originali WINCHMAX in alluminio da 20 mm (set da 4)
Caratteristiche
- Il design del collare di centraggio del mozzo facilita il montaggio e aumenta la stabilità.
- Progettato con precisione utilizzando fresatrici CNC di ultima generazione, garantisce una perfetta aderenza e finitura.
- Realizzato in alluminio aeronautico 6061T6 per la massima leggerezza e resistenza.
- Splendida finitura anodizzata per una maggiore resistenza alla corrosione e durata.
- Specifiche dei bulloni ruota ad alta resistenza (grado 10.9) notevolmente migliorate rispetto ai componenti OE standard.
- Aumenta il passo di 40 mm per una migliore maneggevolezza e stabilità.
- Consente il montaggio di cerchi più larghi e Pneumatici.
- Può migliorare il raggio di sterzata.
- Compatibile con Ford Kuga tutti gli anni, Mondeo 2000-2007, Ford Cmax 2003 su Transit Connect 2003-2013, Ford Focus MK2, MK3.
- Diametro primitivo (PCD): 5 x 108 Filettatura: 12 x 1,5 mm Foro centrale: 63,4 mm
-
Documenti PDF
-
WINCHMAX wheel spacers are precision made and will offer you many years of use if fitted and used correctly. Fitting must be undertaken by a suitably competent person in accordance with the vehicle manufacturers handbook and the guidance below. We recommend engaging the services of a professional wheel/tyre specialist.
- Remove wheel in accordance with vehicle handbook.
- Clean the contact surfaces of the rim and the hub (emery cloth/wire brush) to ensure they are free from corrosion and any dirt or grit - check the spacer fits snugly on the hub.
- Secure spacer to the hub using the lug nuts supplied with the spacers. Tighten (crosswise pattern) to the same torque setting specified by the vehicle manufacturer for the wheel fitting.
- Check that the recesses in the rear of the rim will accommodate the stud protrusion from the spacer.
- Re-fit the wheel onto the spacer in accordance with the vehicle handbook.
- Check for security and adequate clearance between the wheel and the vehicle throughout the full steering range 'lock to lock'.
- Re-check torque settings after 20 then 100 miles of driving and as required thereafter.
- If using blind lug nuts please ensure that they tighten correctly against the rim and do not bottom out against the end of the stud.
